NVA-8521-RA,NVA-8522-RA,NVA-8532-RA,NVA-8542-RA,NVA-8552-RA,neuma氣動閥
Technical Data
|
Model
|
NVA-8521-RA
|
NVA-8522-RA
|
NVA-8532-RA
|
NVA-8542-RA
|
NVA-8552-RA
|
|
Position
|
5/2 Way
|
5/3 Way
|
|||
|
Port size
|
G 1/2”
|
||||
|
Effective area
|
50mm2 (Cv=2.79)
|
30mm2 (Cv=1..68)
|
|||
|
Nominal flow
|
2790 Nl/min
|
1680 Nl/min
|
|||
|
Fluid
|
Compressed air
|
||||
|
Pressure range
|
2.5~10 bar (36~144psi)
|
||||
|
Operating temperature
|
5~60°C (41~140°F)
|
||||
|
Weight
|
0.46 kg
|
0.50 kg
|
0.50 kg
|
||
